Brick Panels with insulation


Product

Description

Panels

Joint alignment system

Starter rail

Aluminum, stable with pre-punching and drip nose.

System 40, 60, 80, 100, 120, 130 mm

Rail balancing pieces

To compensate for tolerances in the assembly of facades base - or to support rail. Can be clipped to color head dowels. By combining several pieces of balancing tolerances can be compensated individually 200 pc each type, 3-5-8-10-15 mm

(tile to panel)

Adhesive up to 12 mtr

Facing tile adhesive FK1002 (25kg/30m²) to bond the link facing tiles to foam panel

(Panel to wall)

Adhesive

Adhesive FK1001

(25kg)

Between wall and foam panel approx. 3-4 kg/m² for undergrounds all types.

(tile to tile)

Adhesive

Facing tile adhesive Polyurethane, Koerapur 666/90 A-B Komp., 350 gr

(tile to tile)

Spare

Accessories for 2 K-Pur mixing cartridges

Foam can

Foam can content 750 ml.

For foam chambers and partition patch joining (8-11 tub/100 m²)

The wall only fit our foam gun

Foam can

Foam can content 500 ml, till -5°C

For foam chambers and partition patch joining

Foam gun

Only for use with our PUR foam gun

Foam gun

Foam gun for self-builders all foam cans

EPS plug

Plug for plate socket

Brick-panel maximal 40 and 60 mm (200 pieces)

Joint mortar

Joint mortar KR 25 kg. Approx. 5kg/m². Good environmental stability .

Name/Number	Color
Gray Nr.1
Beige Nr.2
White Nr.3
Aanthracite Nr.4
Black Nr.5
Beige-White Nr.6
Light gray Nr.7
Medium Gray Nr.8
Red Nr.9
Brown Nr.10
Sulfex Nr.12
Old-Stuhr Nr.13
DGB Nr.14
Schwerin II Nr.16
Domitz Nr.17
Varel Nr.18
Lastrup Nr.20
Apricot Nr.21
Venetian Nr.22
Old-White Nr.23
Yellow Nr.24
Paris Nr.25
Norderney Nr.26
Old-city Nr.27
Stuhr-bright Nr.28
Sudsee Nr.29
Evening-red Nr.30
Beach Nr.31
Nature Nr.32
Tenerife Nr.33
Africa Nr.34
Clay Nr.35
Historic Nr.37

The variety joint mortar KR and joint mortar performance water repellent can be combined.

The highly water-resistant joint mortar change color when it rains, unlike the joint mortar KR.

Therefore, make sure that gaped at the two mortars combination only the whole area and not be flowing around corner areas.

Joint mortar special

Special for all the above varieties in high-performance water repellent especially for weather change

Joint sealing tape

15 mm wide/3mm pressed / roll 10 m / grey
15 mm wide/6 mm pressed / roll 5,6 m / grey
other thicknesses on request-also available in black

Patented sleeve for the mounting of dowels

Thanks to our new dowel fixing case, our system has become yet more stabile and durable.

The patented fixing bush with ISO sealing (DE Patent 101 39 261.3-25) Optimum guiding for plugs and screws (Norista A4 stainless steel or galvanized). No compression of heat insulation, because bush is provided with an arresting element towards the wall! No thermal bridges via polystyrene plugs in front of the screw heads.

DE-Patent 101 39 261.3-25

Illustration shows: Screw head with EPS-plugs
